CAP./SIZE

L

L1

L2

L3

L4

W/H1

H

H2

H3

D

M

0.1~0.5t

130

12.7

25.4

76.2

54

31.8

33.8

14.2

3.5

12.5

M12

1~3t

130

12.7

25.4

76.2

54

31.8

33.8

14.2

3.5

12.5

M16

5t

171.5

19.1

38.1

95.3

77

38.1

41

14

4.5

21

M18*1.5

Item Parameter

C3

Unit

Rated load (Emax):

0.1,0.2,0.5,1,2,3,5

t

Maximal numbers of load cell verification Intervals (Nlc):

3000

d

Minimum load cell verification intervals Intervals

( Vmin):

0.01

% of rated load

Rated output (Cn):

2.0±0.1%

mV/V

Combined error:

0.015

-% of rated output

Temperature effect on sensitivity(Tkc):

0.0012

=% of rated output/

Temperature effect on zero balance(Tk0):

0.0008

-% of rated output

Zero balance:

1.0

-% of rated output

Input resistance(Rlc):

385±5

Ω(Ohms)

Output resistance(Ro):

351±2

Ω(Ohms)

Insulation resistance:

≥5000

MΩ (Mega-Ohms)

Safe overload:

150

% of rated capability

Ultimate overload:

300

% of rated capability

Operating temperature range:

-20~+70/-20~+160

℃/ °F

Recommend excitation:

8~15

V( DC or AC)

Maximum excitation:

18

V( DC or AC)

Material of elastomer:

Alloy steel / Stainless steel

Protection class:

IP67/IP68
